Processing capacity > 200-1000kg/m2h, using electric < 0.5kwh/th, compared with the traditional disk and filter, saving more than 80% of energy consumption. Perfect automatic protection function: automatic fault alarm system, fault screen display function, high and low liquid level display, and automatic elimination or shutdown.
Energy saving and high efficiency: large capacity and obvious power saving effect.
Processing capacity > 200-1000kg/m2h, using electric < 0.5kwh/th, compared with the traditional disk and filter, saving more than 80% of energy consumption.
Automatic control: high performance series automatic control, automatic feeding and automatic cleaning are used to reduce the labbor inensity of operators and reduce the unmber of operators.
Perfect automatic protection function: automatic fault alarm system, fault screen display function, high and low liquid level display, and automatic elimination or shutdown.
The structure is strong and durable: The machine is optimized by microcomputer, with reasonable sturcture and reliable operaion. The main transmission parts are designed without maintenance, reducing the rate of failure shutdown. The stainless steel structure is adopted in the mixing system, ensuring the service life of up to 10 years.
Improve product quality and reduce transportation cost: because the moisture content of filter cake after filtration is very low, it can greatly inprove the market competitiveness of products and reduce transport costs and losses in transporation process.
The effect of environmental protection is obvious: as the filtrate is clear, it can be used repeatedly to reduce the emission, which is in line with the current environmental protection trend of clean production.
| Model | Filtration area (m²) | Number of filter plates | Weight (t) | Installed power | Filter disc rotation speed (r/min) | Overall dimensions (mm) |
| 4-1 | 12 | 48 | 3.1 | 11.25 | 0.1-3 | 3900*3100*2600 |
| 4 | 20 | 48 | 3.8 | 11.4 | 0.1-3 | 3900*3300*3000 |
| 5 | 25 | 60 | 4.7 | 12.2 | 0.1-3 | 4700*3300*3000 |
| 6 | 30 | 72 | 5.3 | 12.2 | 0.1-3 | 5000*3300*3000 |
| 8 | 40 | 96 | 6.4 | 20 | 0.1-3 | 5600*3300*3000 |
| 10 | 50 | 120 | 8.2 | 20 | 0.1-3 | 6200*3300*3000 |
| 12 | 60 | 144 | 10.3 | 20 | 0.1-3 | 6800*3300*3000 |
| 15 | 75 | 180 | 12.5 | 27.5 | 0.1-3 | 7700*3300*3000 |
| 18 | 90 | 216 | 14.8 | 37 | 0.1-3 | 8600*3300*3000 |
| 20 | 100 | 240 | 16.5 | 37 | 0.1-3 | 9000*3300*3000 |
