DTDZ-12/22 Single Arm and Four Lead Pillars Type multi-blades cutter. It lifts with four lead pillars driven by oil cylinder. The parts and accessories comprises of high quality steel. The machine is featured with simple structure and operation, quick lifting and high producing quantity etc.
| Type | Unit | DTQZ-16 |
| Diameter of Blade | mm | Φ1600(Φ2200) |
| Number of blade | P | 16 |
| Lifting distance | mm | 1000(1300) |
| Max. cutting size | m | 3.5*1.3*0.9 |
| Main motor Power | kw | 75/90 |
| Water consumption | m3/h | 30 |
| Weight | kg | 8700 |
| Type | Unit | DTQZ-22 |
| Diameter of Blade | mm | Φ1600(Φ2200) |
| Number of blade | P | 22 |
| Lifting distance | mm | 1000(1300) |
| Max. cutting size | m | 3.5*1.6*0.9 |
| Main motor Power | kw | 110(132) |
| Water consumption | m3/h | 40(44) |
| Weight | kg | 11500 |
